DC12V 12mm RGBW COB LED Strip – High Density 896 LEDs Per Meter

Overview: This DC12V 12mm RGBW COB (Chip on Board) LED strip is designed to offer vibrant and uniform lighting with its high-density configuration of 896 LEDs per meter. Unlike traditional SMD (Surface Mounted Diode) strips, COB technology provides a continuous line of light without visible “dots,” creating a seamless and smooth illumination. This high-density strip delivers stunning performance and flexibility, perfect for architectural lighting, signage, decorative lighting, and dynamic effect applications.

Key Features:

• High-Density COB Technology: The 896 LEDs per meter provide a densely packed array of LEDs, offering a smooth, continuous light output without visible separation between the LEDs.

• RGBW Color Control: This strip features Red, Green, Blue, and White LEDs, allowing for full-spectrum color mixing, as well as pure white light (both warm white and cool white), making it suitable for a wide range of lighting scenarios.

• 12mm Width: This width ensures the strip is compatible with most standard 12mm LED aluminum channels, providing a compact solution for professional installations.

• Flexible and Cuttable: The strip can be cut at designated points (usually every 3 LEDs or 6 LEDs) to match the desired length for your application.

• Low Voltage (12V): Running on a 12V DC power supply, this strip is safer and more energy-efficient for indoor use, reducing the risk of heat buildup and voltage drop.

• IP20 Non-Waterproof: Ideal for indoor applications where the strip is not exposed to moisture or direct water exposure. If outdoor use is required, consider using waterproof versions (IP65/IP67).

• High Lumen Output: Due to its high-density layout, this COB LED strip offers higher brightness compared to regular LED strips, providing excellent illumination for both ambient and task lighting.

• High CRI (Color Rendering Index): The RGBW configuration, along with the high-quality LEDs, ensures vibrant and accurate color rendering, ideal for applications where color accuracy is important (e.g., photography, retail displays).

Specifications:

• Operating Voltage: 12V DC

• LED Type: COB (Chip on Board) RGBW

• LED Density: 896 LEDs per meter

• Width: 12mm

• LED Chip Size: 5050 RGBW

• Power Consumption: Typically 20-24W per meter (depending on the color mix and brightness setting)

• Color Temperature:

  • RGBW (Adjustable color mix)

  • White (Pure Warm White & Cool White options available)

• Cutting Length: Can be cut at every 6 LEDs

• Lifespan: Approximately 50,000 hours

• Operating Temperature: -20°C to +50°C

• CRI (Color Rendering Index): ≥ 80 (for excellent color quality)

• Certifications: CE, RoHS



Applications:

• Architectural Lighting: Ideal for creating elegant, seamless lighting effects in homes, offices, and commercial spaces.

• Signage: Perfect for backlighting signage with vibrant, customizable colors.

• Display Lighting: Suitable for lighting in retail environments, exhibitions, and displays where color accuracy is critical.

• Accent Lighting: Provides beautiful accent lighting for shelves, cabinets, and other architectural features.

• Task Lighting: With the added white LED, it can also serve as effective task lighting in kitchens or workspaces.

• Stage & Event Lighting: Ideal for creating immersive lighting effects in events, theaters, or live shows.

  1.

Installation Instructions:

1. Measure and Plan: Measure the area where you want to install the LED strip and cut the strip to the required length at the designated cut points.

2. Prepare the Surface: Clean the surface where the LED strip will be mounted to ensure good adhesion.

3. Adhesive Backing: The strip has an adhesive backing for easy installation, but for a more permanent solution, you can also use clips or channels.

4. Connect Power: Connect the strip to a suitable 12V DC power supply. Ensure the power supply is rated for the total wattage of the strip (approximately 20W per meter).

5. Controller: To control the colors and effects, use an RGBW controller that is compatible with COB LED strips.

6. Test: Power on the strip and test the color changing and brightness features to ensure everything is functioning as expected.
